Kubota KX121-2 S04200 OIL TANK Parts Diagram
Exploded-view parts diagram "S04200 OIL TANK" for the Kubota KX121-2 and Kubota KX161-2. 21 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | TANK, HYD.OIL RD108-62130 RD108-62132 | 1 | $4,251.07 | |||
| 020 | PLUG RC101-62134 | 1 | $110.36 | |||
| 030 | O-RING 04811-11300 | 1 | $9.11 | |||
| 040 | SUPPORT, FILTER RC301-62160 Discontinued | 1 | $153.02 | |||
| 042 | BOLT 01152-50850 01155-50850 | 1 | $1.85 | |||
| 044 | NUT 02114-60080 02114-70080 | 1 | $0.60 | |||
| 050 | GASKET RC101-62230 | 1 | $10.78 | |||
| 060 | O-Ring Seal 04811-00260 | 1 | $2.19 | |||
| 070 | Return Filter RD108-62140 | 1 | $145.32 | |||
| 080 | Filter 69284-62210 RD411-62210 | 1 | $89.71 | |||
| 090 | GAUGE, OIL 68311-62130 | 1 | $53.91 | |||
| 100 | PLUG 06331-35016 | 1 | $3.61 | |||
| 100 | PLUG, TRANS CASE 06311-55040 | 1 | $13.10 | |||
| 110 | Seal Washer 04717-01610 | 1 | $2.93 | |||
| 110 | Seal Washer 04717-02150 | 1 | $3.59 | |||
| 120 | BOLT 01133-61235 01133-71235 | 1 | $2.47 | |||
| 140 | BOLT 68541-11170 | 1 | $5.72 | |||
| 150 | Spring Washer (Lock Washer) 04512-60100 04512-70100 | 1 | $0.60 | |||
| 160 | BREATHER RC101-62250 | 1 | $31.55 | |||
| 170 | PIPE,BREATHER 68671-62190 Discontinued | 1 | $7.27 | |||
| 180 | BAND, CORD 55311-41261 55311-41260 | 1 | $4.85 | |||
Showing 1 to 21 of 21 parts
