Kubota B6200D T08500 HORIZON MUFFLER [OPTION] Parts Diagram
Exploded-view parts diagram "T08500 HORIZON MUFFLER [OPTION]" for the Kubota B6200D, Kubota B6200E, Kubota B7200D and Kubota B7200E. 14 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | HORIZ. MUFFLER A 67401-85400 | 1 | $628.13 | |||
| 020 | MUFFLER 15541-12110 | 1 | $649.26 | |||
| 030 | MUFFLER COVER 67211-54520 Discontinued | 1 | $214.07 | |||
| 040 | Bolt 01222-50612 01202-50612 | 1 | $1.10 | |||
| 050 | Plain Flat Washer 3J099-05763 04013-50060 | 1 | $0.60 | |||
| 060 | PIPE, MUFFLER 66711-54410 | 1 | $55.20 | |||
| 070 | BAND, MUFFLER 66711-54420 | 1 | $16.70 | |||
| 080 | BOLT 01150-50865 01153-50865 | 1 | $3.14 | |||
| 090 | Plain Washer (Flat Washer) 04013-50800 04013-50080 | 1 | $0.36 | |||
| 100 | Spring Washer 04512-50080 | 1 | $0.87 | |||
| 110 | Nut Fastener W2336-07200 02114-50080 | 1 | $0.60 | |||
| 120 | COVER,MUFFLER FL 67111-53430 | 1 | $315.39 | |||
| 130 | KIT, GEARPUMP RE 67111-53440 | 1 | $279.50 | |||
| 160 | MNL, INSTRUCTION 67401-85410 Discontinued | 1 | $10.80 | |||
Showing 1 to 14 of 14 parts
