Kubota KH-66/H KCL S01600 GOVERNOR Parts Diagram
Exploded-view parts diagram "S01600 GOVERNOR" for the Kubota KH-66/H KCL. 15 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | LEVER, GOVERNOR 15221-56023 15221-56020 Discontinued | 1 | $25.07 | |||
| 020 | LEVER, FORK 15761-56050 | 1 | $570.38 | |||
| 030 | COMP.LEVER,FORK 15761-56040 | 1 | $204.74 | |||
| 040 | FORK LEVER ASSY. 15601-56130 15411-56050 Discontinued | 1 | $426.31 | |||
| 050 | SHAFT, FORK LEVE 15221-56150 | 1 | $21.24 | |||
| 060 | BOLT, F LVR SHAF 15021-56243 15021-56240 | 1 | $3.18 | |||
| 070 | Spring Washer (Spring Lock Washer) 04512-80060 04512-50060 | 1 | $0.36 | |||
| 080 | HOLDER, FORK LEV 15221-56234 15221-56230 | 1 | $69.86 | |||
| 090 | BOLT 15221-66410 | 1 | $24.64 | |||
| 100 | BOLT * 01120-50832 01123-50832 | 1 | $1.87 | |||
| 110 | BOLT * 01123-50628 01023-50628 | 1 | $1.87 | |||
| 120 | Washer 04011-50080 04012-50080 | 1 | $0.26 | |||
| 130 | Plain Washer 04011-50060 04012-50060 | 1 | $0.36 | |||
| 140 | SPRING, START 15221-56482 15221-56480 | 1 | $7.36 | |||
| 150 | SPRING, GOVERNOR 15549-56410 | 1 | $3.29 | |||
Showing 1 to 15 of 15 parts
