Kubota T1760 E90000 KING PIN KIT [OPTION] Parts Diagram
Exploded-view parts diagram "E90000 KING PIN KIT [OPTION]" for the Kubota T1760. 12 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | KIT PIN, KING LH K1142-95400 | 1 | $439.68 | |||
| 020 | COMP PIN, KING L K1142-95410 | 1 | $369.54 | |||
| 030 | ARM, KNUCKLE SER K1122-95450 | 1 | $4.39 | |||
| 040 | SHIM, KING PIN K1122-95460 | 1 | $9.66 | |||
| 050 | IM -T1460, T1560 K1122-95470 Discontinued | 1 | $2.53 | |||
| 060 | KIT PIN, KING RH K1142-95560 | 1 | $83.69 | |||
| 070 | COMP PIN, KING R K1142-95440 | 1 | $167.83 | |||
| 090 | KIT, TENSION BRA K1122-95620 | 1 | $104.66 | |||
| 100 | BRACKET, TENSION K1122-95630 | 1 | $123.45 | |||
| 110 | HOLDER, TENSION K1122-26353 K1122-26350 | 1 | $8.16 | |||
| 120 | EX INSTRUCTIONS, K1122-95640 Discontinued | 1 | $1.36 | |||
| 130 | LABEL SET 1, CAU K1122-65173 K1122-65170 | 1 | $171.77 | |||
Showing 1 to 12 of 12 parts
