Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | PILOT COMBINATION VALVE 335/G4950 | 1 | $1,861.73 | |||
| 2 | ADAPTOR G1/4A-9/16UNF (M) 1620/0002 1620/2051 | 1 | $5.41 | |||
| 3 | ADAPTOR G1/2A-3/4UNF(M) 1620/2054 | 1 | $37.26 | |||
| 4 | ADAPTOR TEE 1 1/16 x 5/8 x 1/2 333/C8735 | 1 | $62.64 | |||
| 5 | PLUG 9/16UNF O RING BOSS 1745/0002 | 1 | $106.02 | |||
| 6 | ADAPTOR 7/8SAE x G1/4A 816/90365 | 1 | $43.32 | |||
| 7 | 'Adapter Pressure Test Point 9/16-18UNF 45/908000 | 1 | $132.58 | |||
| 8 | TEE ADAPTOR M/F/M 816/90389 | 1 | $75.05 | |||
| 9 | HOSE 1/2 BSP LP 1240A 23AP/AA124 | 1 | $69.01 | |||
| 10 | Hose HP, 1/4BSP x 31AP/AA058 | 1 | $36.78 | |||
| 11 | RIVET NUT M8 826/01254 826/01106 | 1 | $1.04 | |||
| 12 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 13 | BOLT M8x100 1315/3320Z | 1 | $7.18 | |||
| 14 | SET SCREW M8x30(KANBAN) 1315/0308Z | 1 | $2.17 | |||
| 15 | P CLIP DIA 25MM H/STATIC 821/10220 | 1 | $9.96 | |||
| 16 | (W) (P) LABEL - ISO-06A TYPE A 332/F5855 | 1 | $1.89 | |||
| 17 | RIVET NUT M10 826/01249 | 1 | $8.20 | |||
| 18 | HPA MINI FILTER 32/925768 | 1 | $508.38 | |||
| 19 | MOUNT pilot line filter 332/E6556 | 1 | $23.47 | |||
| 20 | SET SCREW M6 X 16 GRADE 8.8 1315/0203Z 1315/0203D | 1 | $0.54 | |||
| 21 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 22 | HOSE -04 BSP PILOT 350mm 336/D1679 | 1 | $49.92 | |||
| 23 | ADAPTOR 995/91300 | 1 | $26.80 | |||
| 24 | PLAIN WASHER M10 823/00326 | 1 | $1.78 | |||
| 25 | SET-SCREW M10 L-_30mm 1315/0408Z | 1 | $1.22 | |||
| 27 | 90 DEG ELBOW M/F 816/90077 | 1 | $20.24 | |||
Showing 1 to 26 of 26 parts
Related Assemblies
-
DIAG-E190-55-1-394795 E190-55-1 OTHER HYDRAULIC CIRCUITS SERVO ASSEMBLY, LOWER RH
View Diagram -
DIAG-E190-70-1-394795 E190-70-1 OTHER HYDRAULIC CIRCUITS SERVO
View Diagram -
DIAG-E190-50-1-394795 E190-50-1 OTHER HYDRAULIC CIRCUITS AUXILIARY VALVE
View Diagram
