| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | 409 Tipping Link PNTD (333/R4595 M/C) 333/S6175 | 1 | $2,325.27 | |||
| 2 | Pin - 50 x 201.5 332/S3792 | 1 | $187.60 | |||
| 3 | LINER BEARING LINE 333/S3346 | 1 | $80.29 | |||
| 4 | LINER BEARING LINE 333/S3347 | 1 | $66.85 | |||
| 5 | PIVOT PIN SEAL 60-70-5 813/00427 | 1 | $31.91 | |||
| 6 | PIVOT PIN SEAL 60-50-5 813/00426 | 1 | $7.81 | |||
| 7 | GREASE NIPPLE G1/8A 333/Y6602 1450/0001 | 1 | $0.70 | |||
| 8 | BOLT M12x110 1315/3521D | 1 | $4.63 | |||
| 9 | Nut M12 STD SELF LOCK 1370/0403D | 1 | $1.01 | |||
| 10 | 1 BSPT PLUG 1 BSPT 333/S0117 | 1 | $20.30 | |||
| 12 | PIVOT PIN QH 400/D7028 | 1 | $334.10 | |||
| 13 | LOCKING PLATE 400/N1998 | 1 | $14.55 | |||
| 14 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 15 | SET-SCREW M_8 L-_30mm 1315/0308D | 1 | $1.63 | |||
Showing 1 to 14 of 14 parts
