Kubota L3200H V73000 SWINGING DRAWBAR KIT [OPTION] Parts Diagram
Exploded-view parts diagram "V73000 SWINGING DRAWBAR KIT [OPTION]" for the Kubota L3200H and Kubota L3800H. 5 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | DRAWBAR,FRAME 35080-29730 32430-29730 Discontinued | 1 | $595.80 | |||
| 020 | BOLT 01133-51430 | 1 | $3.14 | |||
| 030 | PIN, JOINT 05122-52070 | 1 | $12.24 | |||
| 040 | Replacement Pin 05515-51600 | 1 | $1.36 | |||
| 050 | LABEL 35260-25340 35200-25340 | 1 | $5.15 | |||
Showing 1 to 5 of 5 parts
