Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | HP FUEL PIPE ASSY #1 CR (BR3) 320/06682 | 1 | $249.13 | |||
| 2 | HP FUEL PIPE ASSY #1 CR (BR3) 320/06676 | 1 | $45.63 | |||
| 3 | HP FUEL PIPE ASSY #2 CR (BR3) 320/06677 | 1 | $45.63 | |||
| 4 | HP FUEL PIPE ASSY #3 CR (BR3) 320/06678 | 1 | $45.63 | |||
| 5 | HP FUEL PIPE ASSY #4 CR (BR3) 320/06679 | 1 | $45.63 | |||
| 6 | HP FUEL PIPE CR (BR3) 320/06680 | 1 | $63.91 | |||
| 7 | GROMMET - CR FUEL PIPE(KANBAN) (BR3) 320/06632 | 1 | $4.80 | |||
| 8 | BRACKET - PIPE SUPPORT (BR3) 320/06681 | 1 | $8.08 | |||
| 9 | SETSCREW M8x16(KANBAN) 1317/0303Z 1319/0303Z | 1 | $6.03 | |||
| 10 | KIT - SEALING CAPS/PLUGS 892/01262 | 1 | $46.82 | |||
Showing 1 to 10 of 10 parts
Related Assemblies
-
DIAG-V11-21-1-403050 V11-21-1 ENGINE HARNESS .
View Diagram -
DIAG-V12-11-1-403050 V12-11-1 FUEL PIPEWORK LOW PRESSURE
View Diagram -
DIAG-V11-11-1-403050 V11-11-1 SWITCHES & SENSORS .
View Diagram
