Kubota M8200-CAB U96801 COMPRESSOR KIT [OLD TYPE] [OPTION] Parts Diagram
Exploded-view parts diagram "U96801 COMPRESSOR KIT [OLD TYPE] [OPTION]" for the Kubota M8200-CAB and Kubota M9000-CAB. 15 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | KIT, COMPRESSOR 3A791-97190 | 1 | $2,414.46 | |||
| 020 | ASSY COMPRESSOR 6A671-97110 6A671-97114 | 1 | $763.30 | |||
| 030 | ASSY CLUTCH 6A671-97310 | 1 | $1,093.05 | |||
| 040 | SCREW, WITH WASH T1065-87320 | 1 | $3.59 | |||
| 050 | ASSY WIRE 6A671-97410 | 1 | $218.38 | |||
| 060 | SHIM T1065-87340 | 1 | $1.44 | |||
| 060 | SHIM T1065-87350 | 1 | $4.11 | |||
| 060 | SHIM T1065-87360 | 1 | $4.11 | |||
| 060 | SHIM T1065-87370 | 1 | $4.11 | |||
| 060 | SHIM (1.0, LS30) T1065-87380 | 1 | $5.61 | |||
| 070 | CIR-CLIP T1065-87440 | 1 | $13.43 | |||
| 080 | CIR-CLIP T1065-87450 | 1 | $13.43 | |||
| 090 | BOLT T1065-87460 | 1 | $3.16 | |||
| 100 | HOSE, DISCHARGE 3A791-72230 | 1 | $688.53 | |||
| 110 | Air Conditioner O-Ring 33760-56970 | 1 | $13.65 | |||
Showing 1 to 15 of 15 parts
Related Assemblies
-
DIAG-U94000-85843 U94000 REARVIEW MIRROR KIT [OLD TYPE] [OPTION]
