| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | BRACKET AUX LEVE 3B791-82480 | 1 | $37.28 | |||
| 020 | M8 Flange Bolt 01754-50816 | 1 | $1.07 | |||
| 030 | ASSY LEVER,AUX.C 3B791-82460 | 1 | $61.49 | |||
| 040 | Lever Pivot Bushing 32530-36810 08511-01220 | 1 | $5.11 | |||
| 050 | SHAFT,AUX.CONT.V 3C651-82930 | 1 | $114.70 | |||
| 070 | BOLT 3G710-71140 | 1 | $3.15 | |||
| 080 | GRIP, LEVER 3P300-43560 | 1 | $19.11 | |||
| 090 | WIRE AUX CONT VA 3B791-82970 | 1 | $196.34 | |||
| 100 | STAY,U 3F740-82420 | 1 | $8.49 | |||
| 110 | WASHER,LOCK 3F740-82430 | 1 | $6.24 | |||
| 120 | Flange Nut 02761-50050 | 1 | $0.60 | |||
| 130 | PIN, JOINT 05122-60618 05122-50618 | 1 | $1.43 | |||
| 140 | Plain Flat Washer 3J099-05763 04013-50060 | 1 | $0.61 | |||
| 150 | Snap Pin 05525-50600 05525-70600 | 1 | $1.48 | |||
| 160 | Plain Washer (Flat Washer) 04013-50800 04013-50080 | 1 | $0.14 | |||
| 170 | PIN, SNAP 05515-50800 | 1 | $0.60 | |||
| 180 | STUD 3C081-93960 | 1 | $40.40 | |||
| 190 | NUT 37300-14190 | 1 | $2.36 | |||
| 200 | Spring Washer, Metric (M) 04512-50100 | 1 | $0.67 | |||
| 210 | STUD 3C081-93970 | 1 | $40.40 | |||
| 220 | NUT * 35320-25470 | 1 | $2.54 | |||
| 230 | Spring Washer 04512-50080 | 1 | $0.14 | |||
| 240 | STUD 3C081-93950 | 1 | $40.40 | |||
| 270 | STUD 3C081-93940 | 1 | $40.40 | |||
| 300 | LABEL, AUX CON V 3B791-98390 | 1 | $3.83 | |||
Showing 1 to 25 of 25 parts
Related Assemblies
-
DIAG-U71003-194663 U71003 AUXILIARY CONTROL VALVE LEVER KIT (3RD) (W/G No.M9116) [OPTION]
View Diagram -
DIAG-U85000-194663 U85000 ASSIST CYLINDER KIT [OPTION]
View Diagram -
DIAG-U85400-194663 U85400 3P-LIFT ASSIST CYLINDER [COMPONENT PARTS] [OPTION] [OLD]
View Diagram
