Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ROD H-L 3A152-29890 | 1 | $46.98 | |||
| 020 | ROD, CREEP 3A152-31450 | 1 | $39.26 | |||
| 030 | BALL, LINK 4-CRE 54721-31850 | 1 | $53.41 | |||
| 040 | SCREW, LH NUT-CR 31351-24260 | 1 | $1.91 | |||
| 050 | END, ROD (CREEP 45404-95770 | 1 | $27.49 | |||
| 060 | Replacement Nut 02112-60080 02112-50080 | 1 | $0.60 | |||
| 070 | Spring Washer (Lock Washer) 04512-60080 04512-70080 | 1 | $0.60 | |||
| 080 | Nut Fastener W2336-07200 02114-50080 | 1 | $0.60 | |||
| 090 | ASSY LEVER 3 3A152-29910 Discontinued | 1 | $105.94 | |||
| 100 | BUSH 76535-34880 08511-02812 | 1 | $10.60 | |||
| 110 | ASSY SUPPORT(CRE 3A152-29700 | 1 | $273.97 | |||
| 120 | BUSH (CREEP SPEE 08511-01910 | 1 | $8.57 | |||
| 130 | BUSH (CREEP SPEE 31351-17320 08511-01412 | 1 | $5.05 | |||
| 140 | LEVER,SELECT 3A152-29960 | 1 | $228.63 | |||
| 150 | Washer 04011-50140 | 1 | $0.60 | |||
| 160 | Plain Washer 04015-60100 04015-70100 | 1 | $1.05 | |||
| 170 | Nut (Fastener) 02117-50100 02118-50100 | 1 | $0.80 | |||
| 175 | Plain Washer (Flat Washer) 04013-50180 | 1 | $0.60 | |||
| 180 | GUIDE, LEVER(CRE 3A011-29730 | 1 | $104.45 | |||
| 190 | CUSHION LEVER GU 3A152-29740 | 1 | $121.66 | |||
| 200 | MARK RANGE SHIFT 3A131-98960 | 1 | $35.07 | |||
| 210 | LABEL SPEED,M820 3A131-98450 Discontinued | 1 | $3.40 | |||
Showing 1 to 22 of 22 parts
Related Assemblies
-
DIAG-U32200-85847 U32200 CREEP SPEED KIT (SHIFT FORK) [A] [OPTION]
View Diagram -
DIAG-U35000-85847 U35000 PTO(540/1000) CONVERSION KIT (GEAR CASE) [OPTION]
View Diagram -
DIAG-U32000-85847 U32000 CREEP SPEED KIT (GEAR/SHAFT) [A] [OPTION]
View Diagram
