Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 2 | TUBRO 2, INLET 7 T 332/U4170 | 1 | $3,622.45 | |||
| 3 | PUMP SUCTION PIPE 332/U4085 | 1 | $66.45 | |||
| 4 | AIR CLEANER ASSY 1 333/U2506 | 1 | $741.24 | |||
| 5 | INDUCTION HOSE 333/R3833 | 1 | $389.23 | |||
| 7 | CLIP - WORMDRIVE 184/206mm 2201/0023 | 1 | $33.90 | |||
| 8 | WORM DRIVE SPRING CLIP 13 2206/1315 | 1 | $25.41 | |||
| 9 | BAND CLAMP ; AIR CLEANER 332/T0026 | 1 | $113.51 | |||
| 10 | AIR CLEANER MTG - WA 333/S5469 | 1 | $183.42 | |||
| 11 | SET-SCREW M10 L-_25mm 1315/0407D | 1 | $0.62 | |||
| 12 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 13 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 14 | SET-SCREW M10 L-_20mm 1315/0405D | 1 | $4.43 | |||
| 15 | SET-SCREW M_8 L-_20mm 1315/0305D | 1 | $10.29 | |||
| 16 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 17 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 27 | 54m BAR SWITCH (EM&LP) 335/D3073 716/F2027 | 1 | $76.83 | |||
Showing 1 to 16 of 16 parts
Related Assemblies
-
DIAG-U3-4-2-404996 U3-4-2 FILTER, AIR COMPONENTS
View Diagram -
DIAG-U3-6-1-404996 U3-6-1 FILTER, AIR COMPONENTS TURBO PRE-CLEANER
View Diagram -
DIAG-U3-3-2-404996 U3-3-2 FILTER, AIR
View Diagram
