Kubota RTV-X1130R U14300 CARGO LAMP KIT (LAMP) [OPTION] (K7921-99570) Parts Diagram
Exploded-view parts diagram "U14300 CARGO LAMP KIT (LAMP) [OPTION] (K7921-99570)" for the Kubota RTV-X1130R and Kubota RTV-X1130W. 10 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | PLATE(CARGO,LAMP K7921-95710 | 1 | $292.73 | |||
| 020 | Button Screw K1211-54362 K1211-54363 | 1 | $0.80 | |||
| 030 | LAMP, LED K3011-62810 | 1 | $25.58 | |||
| 040 | Screw with Washer 03024-50416 03024-70416 | 1 | $0.60 | |||
| 050 | Hardware Nut 32530-19290 02054-50040 | 1 | $0.36 | |||
| 060 | COVER(PLATE,FRON K7811-58900 | 1 | $25.35 | |||
| 070 | Push Rivet Fastener K1211-84560 | 1 | $2.93 | |||
| 080 | LABEL(SET,COVER K7921-65912 | 1 | $24.01 | |||
| 080 | LABEL(SET,COVER UPPE K7931-65912 | 1 | $15.11 | |||
| 090 | LABEL SET,COVER K7591-65220 K7591-65910 | 1 | $18.13 | |||
Showing 1 to 10 of 10 parts
