| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | HOUSING 02/910964 | 1 | $6,339.90 | |||
| 2 | PLATE 02/910069 | 1 | $26.43 | |||
| 3 | SCREW - FLANGE HEAD M8x16mm 02/911069 | 1 | $12.28 | |||
| 4 | Plug 02/910571 | 1 | $23.19 | |||
| 5 | PLUG 02/910068 | 1 | $31.66 | |||
| 6 | O RING 02/910067 | 1 | $21.80 | |||
| 7 | BOLT 02/911015 | 1 | $23.22 | |||
| 8 | FLYWHEEL ASSY 02/910465 | 1 | $2,326.01 | |||
| 9 | GEAR 02/919993 | 1 | $451.64 | |||
| 10 | BOLT 02/911017 | 1 | $12.17 | |||
| 11 | WASHER 02/911018 | 1 | $6.56 | |||
| 13 | DOWEL 02/910073 | 1 | $49.04 | |||
| 14 | DOWEL PIN 02/910074 | 1 | $49.04 | |||
| 15 | SPACER 02/910075 | 1 | $720.70 | |||
| 16 | STUD 02/911019 | 1 | $33.74 | |||
| 17 | NUT 02/911020 | 1 | $6.60 | |||
| 18 | CLIP 02/910791 | 1 | $12.85 | |||
| 20 | BOLT M10x60 (10.9 GRADE) 1316/3414Z | 1 | $2.86 | |||
| 21 | PLAIN WASHER 823/00171 | 1 | $12.95 | |||
Showing 1 to 19 of 19 parts
