Kubota G4200H T22010 SEAT Parts Diagram
Exploded-view parts diagram "T22010 SEAT" for the Kubota G4200H. 17 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY ADJUSTER,SE 66021-45910 66021-45912 Discontinued | 1 | $78.64 | |||
| 020 | Bolt (Fastener) 01023-50818 01123-50818 | 1 | $0.87 | |||
| 030 | KIT, SEAT 66021-45920 H6600-45900 | 1 | $641.63 | |||
| 040 | PIN, SEAT 32160-18432 38240-18470 | 1 | $9.28 | |||
| 050 | CUSHION 37150-18490 | 1 | $11.23 | |||
| 060 | Snap Pin Retaining Pin 05515-51000 | 1 | $1.51 | |||
| 070 | CUSHION 38240-18440 | 1 | $5.31 | |||
| 080 | COLLAR 35260-18500 | 1 | $8.02 | |||
| 090 | Plain Washer (Flat Washer) 04013-50800 04013-50080 | 1 | $0.36 | |||
| 100 | Spring Pin 05511-00218 05511-50218 | 1 | $0.36 | |||
| 110 | Joint Pin 05112-50850 05122-50850 | 1 | $2.93 | |||
| 120 | SUPPORT, SEAT 66021-45930 Discontinued | 1 | $44.41 | |||
| 150 | COVER, RUBBER** 66021-45940 | 1 | $1.29 | |||
| 160 | SEAT COVER ASSY. 66021-83500 Discontinued | 1 | $112.93 | |||
| 170 | SEAT COVER 66021-83110 Discontinued | 1 | $85.80 | |||
| 180 | EYELET 35110-85050 | 1 | $2.67 | |||
| 190 | ASSY COVER,SEAT 35110-85060 35110-99102 | 1 | $104.64 | |||
Showing 1 to 17 of 17 parts
