Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | SEAT, ASSY R2401-38010 R2401-38013 | 1 | $1,277.61 | |||
| 020 | RAIL A R2401-38110 | 1 | $136.38 | |||
| 030 | RAIL B R2401-38120 | 1 | $118.64 | |||
| 040 | SEAT, COMPLETE R2401-38130 R2401-38132 | 1 | $1,591.91 | |||
| 050 | NUT, FLANGE 02751-60080 02751-70080 | 1 | $4.62 | |||
| 060 | ASSY TURNTABLE R2401-38300 R2401-38303 | 1 | $1,936.27 | |||
| 060 | BASE,SEAT R2401-38210 | 1 | $1,215.61 | |||
| 070 | KIT, BRACKET BEL TA040-18503 TA040-99700 | 1 | $611.69 | |||
| 080 | BOLT 01176-61035 01176-51035 | 1 | $3.02 | |||
| 090 | M10 Plain Washer 04013-60100 04013-70100 | 1 | $0.60 | |||
| 100 | NUT 02176-60100 02176-70100 | 1 | $1.75 | |||
| 110 | WIRE R2401-38220 | 1 | $118.98 | |||
| 120 | BRACKET, SMV 68817-43480 | 1 | $25.38 | |||
| 130 | BOLT 01123-60820 01123-70820 | 1 | $1.37 | |||
| 140 | GRIP, LEVER 55411-31620 | 1 | $11.98 | |||
| 150 | PLATE, SPRING 68721-65740 | 1 | $1.87 | |||
Showing 1 to 16 of 16 parts
