Kubota BX1500D S10302 LABEL (REAR) [FRENCH] Parts Diagram
Exploded-view parts diagram "S10302 LABEL (REAR) [FRENCH]" for the Kubota BX1500D. 13 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | 4WD Label K2571-65250 | 1 | $2.15 | |||
| 010 | LABEL, 4WD* K2561-65250 | 1 | $39.08 | |||
| 030 | RIVET, BLIND BLA 32751-34790 K6072-63910 | 1 | $1.93 | |||
| 040 | LABEL, HYD. ADJU K2561-65260 K2561-65263 | 1 | $4.67 | |||
| 050 | LABEL, SET 1 * K2561-65230 K2561-65200 | 1 | $133.64 | |||
| 080 | LABEL SET,2*** K2561-65482 K2511-65402 | 1 | $153.82 | |||
| 090 | LABEL SET, 2 K2561-65460 K2561-65405 | 1 | $49.76 | |||
| 140 | LABEL, PTO WARNI K2581-65540 K2561-65540 Discontinued | 1 | $16.68 | |||
| 150 | LABEL, ADJUST CA K2561-65550 Discontinued | 1 | $9.14 | |||
| 190 | LABEL SET, 2 K2517-65400 | 1 | $87.61 | |||
| 260 | LABEL, DIFF LOCK K2567-65660 | 1 | $77.59 | |||
| 270 | LABEL, ROPS WARN 6C141-47460 6C140-47460 | 1 | $4.26 | |||
| 280 | LABEL, REFLECTOR K2591-65410 | 1 | $7.75 | |||
Showing 1 to 13 of 13 parts
