Kubota KH-191 S04000 SWIVEL MOTOR & COMPONENT PARTS Parts Diagram

Exploded-view parts diagram "S04000 SWIVEL MOTOR & COMPONENT PARTS" for the Kubota KH-191. 33 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.

Scroll to zoom Click a part # to view details

Ref # Part Number Qty. Avl. Price (USD) Action
010 MOTOR, SWING 68493-61280 1 AVAILABLE TO ORDER $5,975.55
020 HOLDER, SPRING 68493-71390 1 AVAILABLE TO ORDER $12.83
021 SHAFT 68493-71350 Discontinued 1 NO LONGER AVAILABLE $441.56
022 BEARING, BALL 68493-71420 Discontinued 1 NO LONGER AVAILABLE $73.99
023 BRGNDLROLLTHRU20 68493-71430 1 AVAILABLE TO ORDER $73.94
024 PIN, STRAIGHT 68493-71440 1 AVAILABLE TO ORDER $30.72
025 SWASHPLATE ASSY 68493-71400 1 AVAILABLE TO ORDER $2,077.78
030 SPRING 68493-71410 1 AVAILABLE TO ORDER $14.23
040 PIN, STRAIGHT 68493-71450 1 AVAILABLE TO ORDER $14.41
050 RING, SNAP 68493-71460 1 AVAILABLE TO ORDER $13.32
060 RING, SNAP 68493-71470 Discontinued 1 NO LONGER AVAILABLE $13.59
070 SEAL, OIL 68493-71480 1 AVAILABLE TO ORDER $65.02
080 GASKET 68493-71490 1 AVAILABLE TO ORDER $26.70
090 BOLT, SOCKET HEA 68493-71510 1 AVAILABLE TO ORDER $17.18
100 VALVE, BRAKE 68493-61260 1 AVAILABLE TO ORDER $2,808.70
110 SEAT, SPRING 68493-71540 1 AVAILABLE TO ORDER $22.14
120 SPRING 68493-71550 1 AVAILABLE TO ORDER $15.78
130 CAP 68493-71560 1 AVAILABLE TO ORDER $97.69
140 O-RING 04810-00290 1 4 IN STOCK $3.69
150 O RING 04810-00160 1 6 IN STOCK $2.21
160 VALVE, RELIEF 68493-71570 1 AVAILABLE TO ORDER $757.41
170 O-Ring Seal 04810-00180 04817-00180 1 42 IN STOCK $2.26
180 O-Ring Seal 04811-00140 04816-00140 1 9 IN STOCK $2.01
190 O-Ring Seal 04810-00120 04817-00120 1 5 IN STOCK $2.50
200 RING, BACK UP 68111-91190 68493-71580 1 AVAILABLE TO ORDER $8.28
210 RING, BACK UP 68493-71590 1 AVAILABLE TO ORDER $18.52
220 PLUG 68493-71610 1 AVAILABLE TO ORDER $97.69
240 SPRING 68493-71630 Discontinued 1 NO LONGER AVAILABLE $12.20
250 KIT,SWING MOTORS 68493-91210 Discontinued 1 NO LONGER AVAILABLE $127.16
260 KIT, SEAL RELIEF 68493-91220 1 AVAILABLE TO ORDER $32.09
270 O'RING 04811-11000 1 1 IN STOCK $8.08
280 BOLT 01173-61435 Discontinued 1 NO LONGER AVAILABLE $3.12
290 WASHER,SPRING 04512-60140 04512-70140 1 14 IN STOCK $0.36

Showing 1 to 33 of 33 parts
