Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ALTERNATOR,ASSY 16241-64010 1J022-64010 | 1 | $353.63 | |||
| 010 | REMAN ASSY ALTER 77700-02592 77700-07917 | 1 | $205.35 | |||
| 020 | STAY, DYNAMO * 16241-64420 16241-64422 | 1 | $13.15 | |||
| 030 | Bolt (Fastener) 01120-00830 01123-50830 | 1 | $1.37 | |||
| 040 | BOLT 01114-51085 01173-51085 | 1 | $4.09 | |||
| 050 | Hex Nut, M10-1.25mm (6T) 70090-33403 02176-50100 | 1 | $0.80 | |||
| 060 | Plain Washer 04011-00100 04011-50100 | 1 | $0.36 | |||
| 070 | Spring Washer (Lock Washer) 04512-60100 04512-70100 | 1 | $0.60 | |||
| 090 | Bolt 01023-50168 01023-50618 | 1 | $1.10 | |||
| 100 | Plain Washer 04011-50060 04012-50060 | 1 | $0.36 | |||
| 110 | CLAMP, CORD 16271-83370 | 1 | $5.59 | |||
| 120 | FAN 16206-74112 | 1 | $118.69 | |||
| 130 | PULLEY, FAN 16217-74250 | 1 | $61.67 | |||
| 140 | BOLT, FLANGE 01754-50650 | 1 | $5.71 | |||
| 150 | PULLEY, FAN DRIV 16281-74280 Discontinued | 1 | $28.21 | |||
| 160 | BOLT 16241-91020 | 1 | $16.71 | |||
| 170 | Fan Belt 16206-97012 16206-97013 | 1 | $24.86 | |||
| 180 | COLLAR, FAN 17036-74152 | 1 | $196.67 | |||
Showing 1 to 18 of 18 parts
Related Assemblies
-
DIAG-S03200-85181 S03200 ALTERNATOR [COMPONENT PARTS](NOT FOR REMAN UNIT)
View Diagram -
DIAG-S03300-85181 S03300 BATTERY
View Diagram -
DIAG-S112-2-85180 S112-2 WEIGHT (TELESCOPIC)
View Diagram
