| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | STARTER, ASSY** 19269-63013 19269-63010 | 1 | $492.07 | |||
| 020 | YOKE ASSY 19215-63080 | 1 | $347.64 | |||
| 030 | ARMATURE 15511-63070 | 1 | $658.08 | |||
| 040 | CLUTCH 19212-63040 | 1 | $485.64 | |||
| 050 | END DRIVE FRAME 19269-63030 | 1 | $179.81 | |||
| 060 | SWITCH ASSY 19269-63020 | 1 | $741.11 | |||
| 070 | END FRAME 19269-63200 Discontinued | 1 | $74.33 | |||
| 080 | BRUSH HOLDER ASS 15511-63380 | 1 | $37.98 | |||
| 090 | GEAR 1 15511-63260 Discontinued | 1 | $27.75 | |||
| 100 | GEAR, SPUR 2 15521-63270 15401-63270 | 1 | $57.90 | |||
| 110 | RETAINER 19212-63110 | 1 | $9.63 | |||
| 120 | ROLLER 19212-63100 | 1 | $2.37 | |||
| 130 | SPRING 19212-63120 | 1 | $4.00 | |||
| 140 | BALL, STEEL 15521-97131 19212-97130 | 1 | $1.45 | |||
| 150 | SCREW, PAN HEAD 15501-93310 Discontinued | 1 | $1.59 | |||
| 160 | O-RING 15511-96660 | 1 | $20.24 | |||
| 170 | BOLT 19215-63320 | 1 | $10.47 | |||
| 180 | BOLT 15511-63760 | 1 | $8.66 | |||
| 190 | COVER 19215-63290 | 1 | $15.41 | |||
| 200 | NUT, HEX 13963-92010 | 1 | $5.94 | |||
Showing 1 to 20 of 20 parts
