| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | STARTER, ASSY 15461-63010 1J988-63010 | 1 | $338.53 | |||
| 020 | YOKE 15511-63080 15461-63080 Discontinued | 1 | $460.97 | |||
| 030 | ARMATURE 15511-63070 | 1 | $658.08 | |||
| 040 | BEARING BALL RAD 15511-63500 Discontinued | 1 | $30.74 | |||
| 050 | BEARING BALL RAD 15511-63530 | 1 | $36.03 | |||
| 060 | STARTER CLUTCH 15461-63040 15471-63040 Discontinued | 1 | $413.46 | |||
| 070 | KIT STARTER PINI 17381-63280 | 1 | $55.60 | |||
| 080 | FRAME, DRIVE END 15511-63030 Discontinued | 1 | $128.03 | |||
| 090 | SWITCH, MAGNETIC 15461-63020 17341-63020 Discontinued | 1 | $425.59 | |||
| 100 | KIT,STARTER CONT 15461-63110 | 1 | $80.86 | |||
| 110 | PLUNGER 15461-63990 | 1 | $31.69 | |||
| 120 | GASKET 15461-63520 Discontinued | 1 | $14.30 | |||
| 130 | COVER,SOLENOID 15461-63510 | 1 | $28.82 | |||
| 140 | FRAME, END 15511-63200 Discontinued | 1 | $74.33 | |||
| 150 | BRUSH HOLDER ASS 15511-63380 | 1 | $37.98 | |||
| 160 | SPRING,BRUSH * 15401-63390 | 1 | $3.59 | |||
| 170 | GEAR 1 15511-63260 Discontinued | 1 | $27.75 | |||
| 180 | GEAR, SPUR 2 15521-63270 15401-63270 | 1 | $57.90 | |||
| 190 | RETAINER 19212-63110 | 1 | $9.63 | |||
| 200 | ROLLER 19212-63100 | 1 | $2.37 | |||
| 210 | BALL, STEEL 15521-97131 19212-97130 | 1 | $1.45 | |||
| 220 | SPRING 19212-63120 | 1 | $4.00 | |||
| 230 | SCREW, PAN HEAD 15501-93310 Discontinued | 1 | $1.59 | |||
| 240 | O-RING 15511-96660 | 1 | $20.24 | |||
| 250 | BOLT 15511-63760 | 1 | $8.66 | |||
| 260 | COVER 15511-63450 | 1 | $14.30 | |||
| 270 | NUT, HEX 13963-92010 | 1 | $5.94 | |||
| 280 | COVER, CORD 15504-63120 | 1 | $12.89 | |||
| 290 | BOLT 19215-63320 | 1 | $10.47 | |||
| 300 | WASHER, SPRING 13801-94100 | 1 | $1.83 | |||
Showing 1 to 30 of 30 parts
