Kubota M105S-CAB P16000 COMPRESSOR Parts Diagram
Exploded-view parts diagram "P16000 COMPRESSOR" for the Kubota M105S-CAB, Kubota M105SDT-CAB, Kubota M105SDT-CAB-CAN, Kubota M95SDT-CAB and Kubota M95SDT-CAB-CAN. 22 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY COMPRESSOR 6A671-97110 6A671-97114 | 1 | $763.30 | |||
| 020 | ASSY CLUTCH 6A671-97310 | 1 | $1,093.05 | |||
| 020 | ASSY CLUTCH, MAG T1065-87310 T3635-87310 | 1 | $964.20 | |||
| 030 | SCREW, WITH WASH T1065-87320 | 1 | $3.59 | |||
| 040 | ASSY WIRE 6A671-97410 | 1 | $218.38 | |||
| 050 | SHIM T1065-87340 | 1 | $1.44 | |||
| 050 | SHIM T1065-87350 | 1 | $4.11 | |||
| 050 | SHIM T1065-87360 | 1 | $4.11 | |||
| 050 | SHIM T1065-87370 | 1 | $4.11 | |||
| 050 | SHIM (1.0, LS30) T1065-87380 | 1 | $5.61 | |||
| 060 | CIR-CLIP T1065-87440 | 1 | $13.43 | |||
| 070 | CIR-CLIP T1065-87450 | 1 | $13.43 | |||
| 080 | BOLT T1065-87460 | 1 | $3.16 | |||
| 090 | PULLEY 1, TENSIO 3G710-50090 | 1 | $132.82 | |||
| 100 | NUT *** 3A761-72340 | 1 | $12.79 | |||
| 110 | BOLT, FLANGE 01754-50880 | 1 | $7.23 | |||
| 120 | BOLT 01155-50880 | 1 | $3.47 | |||
| 130 | Air Conditioner Compressor Tension Pulley 33760-50090 | 1 | $60.65 | |||
| 140 | M10 Plain Washer 04013-60100 04013-70100 | 1 | $0.60 | |||
| 150 | Spring Washer (Lock Washer) 04512-60100 04512-70100 | 1 | $0.60 | |||
| 160 | Nut 02114-60100 02114-50100 | 1 | $0.80 | |||
| 170 | V BELT *** 3A761-79320 | 1 | $20.17 | |||
Showing 1 to 22 of 22 parts
