Kubota B3030HSDC P12500 COMPRESSOR Parts Diagram
Exploded-view parts diagram "P12500 COMPRESSOR" for the Kubota B3030HSDC and Kubota B3030HSDCC. 22 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| ASSY CLUTCH 6A671-97310 | 1 | $1,093.05 | ||||
| ASSY COMPRESSOR 6A671-97110 6A671-97114 | 1 | $763.30 | ||||
| ASSY WIRE 6A671-97410 | 1 | $218.38 | ||||
| BOLT 6A671-75342 | 1 | $11.17 | ||||
| BOLT T1065-87460 | 1 | $3.16 | ||||
| BOLT * 01123-50870 | 1 | $2.36 | ||||
| Bolt Fastener 01130-51030 01133-51030 | 1 | $2.54 | ||||
| Bolt Fastener for Equipment Assemblies 01120-50820 01123-50820 | 1 | $0.99 | ||||
| BRACKET, COMPRES 6C230-75315 6C230-75318 | 1 | $241.49 | ||||
| CIR-CLIP T1065-87440 | 1 | $13.43 | ||||
| CIR-CLIP T1065-87450 | 1 | $13.43 | ||||
| Flange Nut 02783-50100 | 1 | $6.24 | ||||
| Nut Fastener W2336-07200 02114-50080 | 1 | $0.60 | ||||
| PULLEY 1, TENSIO 3G710-50090 | 1 | $132.82 | ||||
| SCREW, WITH WASH T1065-87320 | 1 | $3.59 | ||||
| SHIM T1065-87340 | 1 | $1.44 | ||||
| SHIM T1065-87350 | 1 | $4.11 | ||||
| SHIM T1065-87360 | 1 | $4.11 | ||||
| SHIM T1065-87370 | 1 | $4.11 | ||||
| SHIM (1.0, LS30) T1065-87380 | 1 | $5.61 | ||||
| STAY (COMPRESSOR 6C230-75322 | 1 | $60.30 | ||||
| V BELT, COMPRESS 6C230-75350 | 1 | $27.77 | ||||
Showing 1 to 22 of 22 parts
