Kubota L4740HSTC-3 N12002 CONDENSER Parts Diagram
Exploded-view parts diagram "N12002 CONDENSER" for the Kubota L4740HSTC-3. 27 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | CONDENSER T1275-72220 | 1 | $1,270.29 | |||
| 020 | Air Conditioner Receiver T0070-79270 | 1 | $166.31 | |||
| 030 | ASSY HOSE TD170-72303 | 1 | $1,418.62 | |||
| 035 | CAP (L) T1855-72350 | 1 | $7.62 | |||
| 040 | O-RING 33760-56980 | 1 | $13.65 | |||
| 050 | ASSY HOSE TD170-72332 TD170-72402 | 1 | $974.72 | |||
| 060 | Air Conditioner and Condenser Hose O-Ring 33760-56960 | 1 | $13.65 | |||
| 070 | ASSY SWITCH PRES 3A761-96290 | 1 | $117.45 | |||
| 080 | JOINT T1275-72350 | 1 | $47.58 | |||
| 090 | Flange Bolt 01754-50620 | 1 | $2.95 | |||
| 100 | HOSE, DISCHARGE TD170-72312 | 1 | $557.02 | |||
| 105 | CAP (H) T1415-72360 | 1 | $7.62 | |||
| 110 | Air Conditioner O-Ring 33760-56970 | 1 | $13.65 | |||
| 120 | Replacement Bolt 01754-50640 | 1 | $4.09 | |||
| 130 | PIPE TD170-72320 TD170-72323 | 1 | $109.68 | |||
| 150 | JOINT T0270-87170 | 1 | $86.18 | |||
| 170 | Bolt 01020-50625 01023-50625 | 1 | $1.37 | |||
| 200 | HOLDER, RECEIVER 3Y205-79360 T0180-79380 | 1 | $24.29 | |||
| 210 | Bolt Fastener for Equipment Assemblies 01120-50820 01123-50820 | 1 | $0.99 | |||
| 220 | GUIDE T1275-74894 | 1 | $24.07 | |||
| 230 | GUIDE,CONDENSER T1275-74880 T1275-74885 | 1 | $23.43 | |||
| 240 | Flange Bolt 01754-50612 | 1 | $1.87 | |||
| 250 | NET, CONDENSER T1275-79312 | 1 | $61.52 | |||
| 260 | COVER, HEATER HO TD170-74872 | 1 | $15.52 | |||
| 270 | CLAMP, HOSE T1855-72590 | 1 | $13.43 | |||
| 280 | STAY, HOSE CLAMP T1065-74903 | 1 | $10.11 | |||
| 290 | Flange Bolt - M8 x 1.25 x 16 mm 01754-50816 | 1 | $4.33 | |||
Showing 1 to 27 of 27 parts
