| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | NOZZLE, WASHER V0511-34990 | 1 | $59.79 | |||
| 020 | TUBE, WASHER V0511-35842 | 1 | $20.08 | |||
| 030 | STAY 34070-71180 | 1 | $22.29 | |||
| 040 | Nut 02021-50060 | 1 | $1.07 | |||
| 050 | ASSY TANK 6A741-74230 | 1 | $187.22 | |||
| 060 | MOTOR (WASHER) 6A671-74240 | 1 | $247.00 | |||
| 070 | TANK 6A741-74240 | 1 | $134.22 | |||
| 080 | BRACKET V0511-34913 | 1 | $160.20 | |||
| 090 | Bolt V0511-35620 | 1 | $1.07 | |||
| 100 | ASSY MOTOR,WIPER * V0511-35800 V0511-35802 | 1 | $606.16 | |||
| 110 | NUT 3P300-57510 | 1 | $3.16 | |||
| 120 | CAP, REAR WIPER 3P300-57470 | 1 | $19.62 | |||
| 130 | DED 3P300-57450 | 1 | $8.09 | |||
| 140 | WASHER 3P300-57440 | 1 | $2.50 | |||
| 150 | SEAL, REAR WIPER 3P300-57430 | 1 | $20.34 | |||
| 160 | PLATE 3P300-57462 | 1 | $146.23 | |||
| 170 | COVER , REAR WIP 3P300-57500 | 1 | $172.46 | |||
| 180 | BOLT 3P300-57492 | 1 | $21.53 | |||
| 190 | CUSHION, REAR WI 3P300-57480 | 1 | $19.24 | |||
| 200 | Flange Nut 02751-50060 | 1 | $0.60 | |||
| 210 | Wiper Blade Assembly V0511-35810 | 1 | $34.70 | |||
| 220 | Windshield Wiper Arm Assembly V0511-35820 | 1 | $126.82 | |||
Showing 1 to 22 of 22 parts
