Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | BRACKET SEAT (NE 3C001-85150 3C001-85152 Discontinued | 1 | $179.00 | |||
| 010 | BRACKET, SEAT (S 3C001-85153 | 1 | $284.15 | |||
| 020 | KIT COLLAR (SEAT 3C001-85310 3C001-97010 | 1 | $29.88 | |||
| 030 | CUSHION (2,SEAT) 3C001-85320 Discontinued | 1 | $24.48 | |||
| 040 | WASHER * 53511-27170 | 1 | $1.91 | |||
| 050 | COLLAR * TD060-23790 | 1 | $38.30 | |||
| 060 | BOLT 01170-51020 01173-51020 | 1 | $1.21 | |||
| 060 | Stud 01517-51030 01517-71030 | 1 | $1.93 | |||
| 070 | Spring Washer (Lock Washer) 04512-60100 04512-70100 | 1 | $0.60 | |||
| 080 | Nut (Fastener) 02117-50100 02118-50100 | 1 | $0.80 | |||
| 085 | COLLAR (BRACKET, 3C001-85340 | 1 | $8.49 | |||
| 090 | ASSY SEAT 3C081-85013 | 1 | $1,638.69 | |||
| 100 | ASSY SUSPENSION 3C081-85022 | 1 | $1,217.74 | |||
| 110 | NUT, FLANGE 02763-50080 | 1 | $4.85 | |||
| 120 | STAY SEAT BELT TD060-47760 TD060-47764 | 1 | $15.51 | |||
| 130 | KIT BELT,SEAT TD060-47780 K3181-56882 | 1 | $151.62 | |||
| 140 | Flange Bolt 01774-61020 01774-71020 | 1 | $1.86 | |||
| 150 | Bolt Fastener 01754-50820 | 1 | $0.54 | |||
| 160 | replaces #01135-61025 BOLT 01135-61025 01135-71025 | 1 | $2.47 | |||
Showing 1 to 19 of 19 parts
