Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | STEP K3281-53010 | 1 | $163.33 | |||
| 020 | Bolt Fastener 01754-50820 | 1 | $4.70 | |||
| 030 | Short Square Bolt K1122-91330 K1122-91332 | 1 | $0.60 | |||
| 040 | Flange Nut TA140-18310 02751-50080 | 1 | $4.62 | |||
| 050 | KIT STEP, OPEN,C K3286-95530 | 1 | $646.25 | |||
| 060 | STEP,KIT(OPEN) K3282-95532 | 1 | $436.96 | |||
| 100 | ROD (OPEN) K3181-53153 | 1 | $8.90 | |||
| 110 | PIN, SNAP 05515-50800 | 1 | $0.60 | |||
| 120 | HANDRAIL, HOOD 5H601-35980 | 1 | $24.44 | |||
| 130 | SCREW, BINDING H 03017-50616 | 1 | $0.36 | |||
| 140 | Lock Nut (Locknut) W2336-06100 02552-50060 | 1 | $1.51 | |||
| 160 | CUSHION K3181-56460 | 1 | $1.62 | |||
| 170 | MAT, STEP K3181-53124 | 1 | $58.91 | |||
| 180 | Push Rivet Fastener K1211-84560 | 1 | $2.93 | |||
| 190 | MAT, STEP OPEN K3181-53130 | 1 | $16.39 | |||
| 210 | ASSY WIRE (LOCK) K3181-53082 | 1 | $5.13 | |||
| 220 | PIN, JOINT 05122-50612 | 1 | $1.91 | |||
| 230 | PIN, SPLIT 05511-11615 05511-51615 | 1 | $0.36 | |||
| 240 | Snap Pin 05525-50600 05525-70600 | 1 | $1.48 | |||
| 250 | Plain Flat Washer 3J099-05763 04013-50060 | 1 | $0.60 | |||
| 260 | Plain Washer (Flat Washer) 04015-50060 | 1 | $0.60 | |||
| 270 | MARK, K SYMBOL K7501-54180 | 1 | $26.50 | |||
| 280 | Nut (Fastener) K1122-89480 K7561-54190 | 1 | $0.51 | |||
| 290 | Plate Washer K7581-44210 55611-44210 | 1 | $1.31 | |||
| 290 | Washer Plate K3111-53330 | 1 | $1.62 | |||
Showing 1 to 25 of 25 parts
