Kubota BX23S M20901 LEVER GUIDE RH Parts Diagram
Exploded-view parts diagram "M20901 LEVER GUIDE RH" for the Kubota BX23S. 11 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | GUIDE(LEVER RH) K2871-55222 | 1 | $25.92 | |||
| 020 | M6 Flange Bolt 01754-50616 | 1 | $2.36 | |||
| 030 | STAY,LEVER GUIDE K2871-55243 | 1 | $29.40 | |||
| 040 | Flange Nut 02771-50100 | 1 | $3.06 | |||
| 050 | HANDRAIL(RH) K2871-55323 | 1 | $28.88 | |||
| 065 | Plain Washer (Flat Washer) 04013-10100 04013-50100 | 1 | $0.60 | |||
| 070 | STOPPER, INCHING K2871-55250 | 1 | $11.14 | |||
| 080 | STOPPER, INCHING K2871-55260 | 1 | $9.40 | |||
| 090 | Short Square Bolt K1122-91310 K1122-91312 | 1 | $0.60 | |||
| 100 | Flange Nut TA140-18310 02751-50080 | 1 | $4.62 | |||
| 110 | PLUG, 3RD FUNCTI K2871-38440 | 1 | $2.64 | |||
Showing 1 to 11 of 11 parts
