Kubota M8540DT M12702 HOOD(BONNET) SIDE COVER Parts Diagram
Exploded-view parts diagram "M12702 HOOD(BONNET) SIDE COVER" for the Kubota M8540DT, Kubota M8540DT-1, Kubota M8540HD, Kubota M8540HD-1, Kubota M8540HD12 and Kubota M8540HD12-1. 12 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | COVER (SIDE, R) 3C081-83370 | 1 | $164.75 | |||
| 010 | COVER,RH 3C081-83372 3C081-83373 | 1 | $42.90 | |||
| 020 | COVER (SIDE, L) 3C081-83380 | 1 | $164.75 | |||
| 020 | COVER,LH 3C081-83382 3C081-83383 | 1 | $47.26 | |||
| 030 | ROD, RELEASE 3C081-83410 | 1 | $13.43 | |||
| 040 | BOLT, FLANGE 30400-18870 | 1 | $1.07 | |||
| 050 | STAY, COVER RH 3C081-83390 3C081-83392 | 1 | $26.28 | |||
| 060 | Flange Bolt 01754-50812 | 1 | $3.93 | |||
| 070 | STAY (COVER, LH) 3C081-83402 | 1 | $14.86 | |||
| 080 | BOLT 01133-51085 | 1 | $4.40 | |||
| 080 | BOLT, FLANGE 01774-51090 | 1 | $5.68 | |||
| 090 | Flange Nut 02771-50100 | 1 | $3.06 | |||
Showing 1 to 12 of 12 parts
