Kubota B2650HSDC M12000 SIDE COVER Parts Diagram
Exploded-view parts diagram "M12000 SIDE COVER" for the Kubota B2650HSDC. 11 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | KIT SKIRT, A 6C430-99300 6C430-99302 | 1 | $114.76 | |||
| 015 | SKIRT,KIT B 6C431-99302 | 1 | $146.65 | |||
| 020 | SKIRT,R 6C430-54352 | 1 | $93.20 | |||
| 030 | STAY,LH SKIRT 6C420-54380 | 1 | $48.49 | |||
| 035 | Bolt Fastener 01130-51030 01133-51030 | 1 | $2.54 | |||
| 040 | BOLT(7T,M6X20) 6C446-54340 | 1 | $2.20 | |||
| 040 | Flange Bolt 01754-50620 | 1 | $2.95 | |||
| 050 | STAY SKIRT, RH 6C420-54392 | 1 | $56.49 | |||
| 060 | Bolt with Washer 01120-50825 01123-50825 | 1 | $1.21 | |||
| 070 | LABEL,START CAUT 6C430-49650 6C430-49652 | 1 | $14.68 | |||
| 080 | LABEL,START CAUT 6C431-49650 | 1 | $16.45 | |||
Showing 1 to 11 of 11 parts
