| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | Housing 234/02818 | 1 | $1,365.30 | |||
| 2 | CAP SCREW M12 X 35LG 1391/3509Z | 1 | $1.97 | |||
| 3 | (W) (P)WASHER 13x23x2.7 823/00309 | 1 | $17.88 | |||
| 5 | DOWEL 02/630018 | 1 | $12.11 | |||
| 6 | SET-SCREW M10 L-_25mm 1315/0407 1315/0407Z | 1 | $5.34 | |||
| 7 | BOLT M10x55 1315/3413Z | 1 | $3.49 | |||
| 8 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 10 | BOLT M10x60 1315/3414Z | 1 | $1.95 | |||
| 11 | SET-SCREW M10 L-_30mm 1315/0408Z | 1 | $1.22 | |||
| 12 | WASHER M10 1422/0008D JHP0046 | 1 | $11.36 | |||
| 13 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 14 | CAP SCREW M10x50 1391/3412Z | 1 | $3.46 | |||
| 15 | CAP SCREW M10x35 1391/3409Z | 1 | $14.72 | |||
| 18 | PLATE 02/634010 | 1 | $115.56 | |||
| 19 | FLYWHEEL ASSY 02/634048 | 1 | $1,585.49 | |||
| 20 | GEAR FLYWHEEL RING 02/634049 | 1 | $283.32 | |||
| 21 | BOLT 02/630775 | 1 | $12.85 | |||
Showing 1 to 17 of 17 parts
