Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 2 | ABI-COOLANT OVERFLOW BOTTLE 333/P3473 | 1 | $35.40 | |||
| 3 | BALL STUD 10mm M8 333/L9832 | 1 | $7.99 | |||
| 4 | GAS STRUT-775N 332/X7264 | 1 | $73.09 | |||
| 5 | BOTTOM HOSE-SP 332/X5288 | 1 | $97.02 | |||
| 6 | BOTTOM HOSE-SP 332/X5289 | 1 | $49.55 | |||
| 7 | TOP HOSE-SP 332/X5252 | 1 | $45.21 | |||
| 8 | TUBE-TOP HOSE JOINT 332/X4364 | 1 | $271.72 | |||
| 9 | COOLANT FLOW BOTTLE 332/X7657 | 1 | $16.46 | |||
| 10 | PRESSING BOTTOM HOSE SUPP 332/X7131 | 1 | $259.42 | |||
| 12 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.00 | |||
| 13 | CLIP 821/10127 | 1 | $17.39 | |||
| 14 | SET-SCREW M_8 L-25mm 1315/0307 1315/0307Z | 1 | $0.37 | |||
| 15 | LINCH PIN 9MMX70MM 826/11496 | 1 | $7.65 | |||
| 16 | NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $6.63 | |||
| 17 | CLIP - WORMDRIVE 35/50mm 2201/0008 | 1 | $5.41 | |||
| 18 | CABLE TIE 190mm 826/01347 | 1 | $3.37 | |||
| 19 | NUT M_8 STD PLAIN 1370/0201Z 1370/0201D | 1 | $0.20 | |||
Showing 1 to 17 of 17 parts
Related Assemblies
-
DIAG-L610-10-1-399886 L610-10-1 COOLING PACK INSTALLATION STANDARD CORE - 135W
View Diagram -
DIAG-L610-10-5-399886 L610-10-5 COOLING PACK INSTALLATION STANDARD CORE - 135W
View Diagram -
DIAG-L610-10-10-399886 L610-10-10 COOLING PACK INSTALLATION STANDARD CORE-135W
View Diagram
