Kubota BX25 K12302 TOP LINK BRACKET Parts Diagram
Exploded-view parts diagram "K12302 TOP LINK BRACKET" for the Kubota BX25. 15 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY BRACKET, FE K2592-39015 K2592-39110 | 1 | $725.24 | |||
| 020 | KIT BRACKET FEND K2597-93920 | 1 | $698.76 | |||
| 020 | KIT BRACKET, FEN K2592-93920 | 1 | $726.60 | |||
| 030 | PLATE, HITCH K2581-39180 | 1 | $17.69 | |||
| 040 | BOLT 01133-51440 | 1 | $3.53 | |||
| 050 | BOLT 01133-51480 | 1 | $6.74 | |||
| 060 | Plain Washer (9) 75599-32516 | 1 | $0.71 | |||
| 090 | NUT, FLANGE 02771-50140 | 1 | $3.16 | |||
| 100 | STAY, FENDER CEN K2581-39130 K2581-39137 | 1 | $378.07 | |||
| 120 | REINFORCEMENT, F K2592-39172 | 1 | $59.20 | |||
| 130 | BOLT, FLANGE 01130-51040 01133-51040 | 1 | $2.87 | |||
| 135 | BOLT 01133-51055 | 1 | $3.14 | |||
| 140 | Flange Nut 02771-50100 | 1 | $3.06 | |||
| 150 | STAY, LIFT ROD K2581-39190 | 1 | $12.01 | |||
| 160 | ROD, TIE K2583-21030 K2583-21032 | 1 | $64.55 | |||
Showing 1 to 15 of 15 parts
