Kubota BX1500D J41000 CONTROL VALVE [COMPONENT PARTS] Parts Diagram
Exploded-view parts diagram "J41000 CONTROL VALVE [COMPONENT PARTS]" for the Kubota BX1500D. 32 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY, VALVE CONT K2561-36402 YR731-00100 | 1 | $1,127.46 | |||
| 020 | ARM K2561-36440 YR731-00220 | 1 | $77.96 | |||
| 030 | WASHER, THRUST K2561-36450 YR535-22170 | 1 | $19.35 | |||
| 040 | O RING 04817-06110 | 1 | $1.91 | |||
| 050 | BALL 07715-00803 | 1 | $0.48 | |||
| 060 | SPRING,SHIFT FOR 67156-18150 | 1 | $5.82 | |||
| 070 | COVER K2561-36462 | 1 | $26.05 | |||
| 080 | O RING 04811-06530 | 1 | $8.09 | |||
| 090 | Bolt Fastener for Equipment Assemblies 01120-50820 01123-50820 | 1 | $0.99 | |||
| 100 | PLUG 06331-35020 | 1 | $5.15 | |||
| 110 | Seal Washer 04717-02000 | 1 | $3.37 | |||
| 120 | CAP 6C040-36620 | 1 | $17.28 | |||
| 130 | O-RING 37410-36630 | 1 | $6.24 | |||
| 140 | Bolt with Washer 01120-50825 01123-50825 | 1 | $1.21 | |||
| 150 | ASSY VALVE K2561-36700 | 1 | $262.01 | |||
| 160 | RELIEF PLUG K2561-36710 YT635-01120 | 1 | $32.45 | |||
| 170 | SPRING, RELIEF 31351-37920 | 1 | $10.25 | |||
| 180 | SEAT, RELIEF (VALVE) 31351-37930 | 1 | $19.68 | |||
| 190 | POPPET 31351-37940 YT450-00220 | 1 | $50.87 | |||
| 200 | Steel Ball 04811-10160 | 1 | $2.19 | |||
| 210 | 0.2 mm Shim Spacer 31351-37960 | 1 | $0.61 | |||
| 210 | Shim 0.4 31351-37950 | 1 | $0.61 | |||
| 210 | Shim, 0.1 Thickness 31351-37970 | 1 | $0.61 | |||
| 220 | Plain Washer 04013-50050 04013-70050 | 1 | $0.60 | |||
| 230 | ASSY VALVE K2561-36800 | 1 | $303.86 | |||
| 240 | O-Ring 04816-06100 | 1 | $1.51 | |||
| 240 | O-RING 04817-06100 | 1 | $1.07 | |||
| 250 | DAMPER 67810-38340 | 1 | $16.39 | |||
| 260 | O-Ring Seal 04810-00220 04817-00220 | 1 | $3.15 | |||
| 270 | O-Ring Seal 04810-00140 04817-00140 | 1 | $2.50 | |||
| 280 | O-Ring Seal for Engine and Hydraulic Components 04815-00160 04817-00160 | 1 | $2.01 | |||
| 290 | ASSY SPOOL, CONT K2561-90300 | 1 | $370.95 | |||
Showing 1 to 32 of 32 parts
