Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | TURRET WA - EXTENDER 335/11347 | 1 | $1,967.14 | |||
| 2 | TRACK LEG WA - L/H EXTEND 333/W0101 334/V0934 | 1 | $782.91 | |||
| 3 | TRACK LEG WA - R/H EXTEND 333/W0100 334/V0750 | 1 | $870.32 | |||
| 7 | EXTENDER RAM 8018/20 400/B2936 | 1 | $1,849.30 | |||
| 8 | Piston grease tens 236/60110 | 1 | $865.66 | |||
| 9 | TRACK ROLLER ASSY 231/98000 332/V6055 | 1 | $230.75 | |||
| 10 | SPECIAL WASHER M12 823/00394 | 1 | $2.96 | |||
| 11 | SET-SCREW M12 L-_25mm 1315/0507D | 1 | $3.38 | |||
| 12 | Pin pivot 236/40001 | 1 | $67.01 | |||
| 13 | WASHER M12 PLAIN 1420/0009D | 1 | $1.07 | |||
| 14 | SET-SCREW M12 L-_30mm 1315/0508D | 1 | $4.54 | |||
| 15 | RAM GUARD 331/42827 | 1 | $165.55 | |||
| 16 | SPACER-14MM 121/93503 | 1 | $2.83 | |||
| 17 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 18 | SET-SCREW M10 L-_30mm 1315/0408D | 1 | $1.55 | |||
| 19 | SLEW RING 821/10322 | 1 | $2,935.83 | |||
| 20 | DOWEL 2105/1609 | 1 | $7.88 | |||
| 21 | Bolt 6009/3509D | 1 | $3.02 | |||
| 22 | (W) (P)WASHER 13x23x2.7 823/00309 | 1 | $17.88 | |||
| 23 | GROMMET 828/00404 | 1 | $16.86 | |||
| 24 | WEAR PAD 331/38811 334/V3587 | 1 | $36.72 | |||
| 25 | SIDE WEAR PAD 331/42828 334/V3630 | 1 | $17.49 | |||
| 27 | COVER PLATE 331/39000 | 1 | $198.20 | |||
| 28 | SET-SCREW M10 L-_25mm 1315/0407D | 1 | $0.62 | |||
| 30 | Bolt M16x100 1316/3720D | 1 | $10.23 | |||
| 31 | WASHER M16 PLAIN 1420/0011D | 1 | $1.43 | |||
| 32 | NUT M16 SELF LOCKING 1371/0603D | 1 | $14.22 | |||
| 33 | WA MOTOR COVER PLATE 332/T5728 | 1 | $216.96 | |||
| 34 | SET-SCREW M_8 L-_20mm 1315/0305D | 1 | $10.29 | |||
| 35 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 36 | -6 ORFS HP 900mm LG 332/P8615 | 1 | $74.11 | |||
| 37 | -6 ORFS HP 860mm LG 332/P8616 | 1 | $72.90 | |||
| 38 | -6 ORFS HP 860mm LG 332/P8618 | 1 | $72.90 | |||
| 39 | -6 ORFS HP 940mm LG 332/P8619 | 1 | $75.58 | |||
| 40 | -4 ORFS PILOT 860mm LG 332/P8627 333/P0689 | 1 | $63.15 | |||
| 41 | -4 ORFS PILOT 1040mm LG 333/P0698 | 1 | $67.74 | |||
| 42 | -4 ORFS HP 560mm LG 333/P6119 | 1 | $71.42 | |||
| 43 | HOSE 1/4" (-4) ORFS HP 68 334/T7419 | 1 | $52.51 | |||
| 44 | HOSE-4 ORFS HP 400 333/P7352 | 1 | $54.58 | |||
| 47 | POLYURETHANE SLEEVING 600mm 332/W8694 | 1 | $36.61 | |||
| 48 | CAP SCREW M10x35 (P960) 1391/3409D | 1 | $4.90 | |||
| 49 | CAPSCREW: M10 x 40 1391/3410D | 1 | $2.23 | |||
| 50 | NUT M10 PLAIN 1370/0301Z 1370/0301D | 1 | $3.28 | |||
| 51 | -4 ORFS PILOT 860mm LG 333/P6092 | 1 | $66.08 | |||
| 52 | -4 ORFS PILOT 1160mm LG 333/P0895 | 1 | $70.59 | |||
| 54 | BOLT M10x65 1315/3415D | 1 | $7.10 | |||
| 55 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 62 | HOSE-4 ORFS HP 400mm C 333/P7349 | 1 | $66.49 | |||
Showing 1 to 48 of 48 parts
