Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | Undercarriage 237/04200 | 1 | $10,957.46 | |||
| 2 | SLEW RING 916/10034 | 1 | $4,306.27 | |||
| 3 | (P) BOLT M12x60 1316/3514Z | 1 | $17.79 | |||
| 3 | BOLT M14 X 70 1316/3616Z | 1 | $3.12 | |||
| 4 | SPECIAL WASHER 823/00540 | 1 | $10.23 | |||
| 5 | DOWEL 826/01290 | 1 | $20.82 | |||
| 6 | COVER TRACK BOX 232/14302 | 1 | $129.03 | |||
| 7 | SET SCREW M10x20 1315/0405Z | 1 | $4.23 | |||
| 9 | PLATE BASE COVER 232/14303 | 1 | $304.92 | |||
| 10 | COVER TENSION 233/31209 | 1 | $120.21 | |||
| 11 | COVER 232/14305 | 1 | $11.48 | |||
| 12 | (W) (Pre-P)-SET SCREW M8x12 1315/0301Z | 1 | $1.92 | |||
| 13 | SPRING WASHER M8 823/00415Z | 1 | $0.30 | |||
| 15 | BOLT M12X35 1315/3509Z | 1 | $1.72 | |||
| 16 | SPRING WASHER M12 823/00417Z | 1 | $0.50 | |||
Showing 1 to 15 of 15 parts
