Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | UNDERCARRIAGE 335/01335 | 1 | $3,963.46 | |||
| 2 | PLATE SKID 233/31001 | 1 | $153.86 | |||
| 3 | BOLT M12x40 1315/3510Z | 1 | $4.66 | |||
| 4 | NUT M12 STD SELF LOCK 1370/0403Z | 1 | $2.11 | |||
| 5 | WASHER M12 PLAIN(KANBAN) 1420/0009Z | 1 | $0.65 | |||
| 6 | GEAR SLEW RING 233/21300 | 1 | $4,575.67 | |||
| 7 | COVER TRACK BOX 232/14302 | 1 | $129.03 | |||
| 8 | SET SCREW M10x20 1315/0405Z | 1 | $4.23 | |||
| 10 | PLATE BASE COVER 232/14303 | 1 | $304.92 | |||
| 11 | SET-SCREW M10 L-_25mm 1315/0407 1315/0407Z | 1 | $5.34 | |||
| 12 | SPRING WASHER M10 823/00416Z | 1 | $0.15 | |||
| 13 | COVER TENSION 233/31209 | 1 | $120.21 | |||
| 14 | (W) (Pre-P)-SET SCREW M8x12 1315/0301Z | 1 | $1.92 | |||
| 15 | SCREW SPECIAL 826/01701 | 1 | $28.47 | |||
| 16 | SPECIAL WASHER M12 823/00394 | 1 | $2.96 | |||
| 17 | SPRING WASHER M8 823/00415Z | 1 | $0.30 | |||
| 18 | SCREW HEX. HEAD 826/01610 | 1 | $6.02 | |||
| 20 | TUBE SPACER 233/31002 | 1 | $37.37 | |||
| 21 | BRACKET ROTARY JOI 331/17154 | 1 | $135.99 | |||
Showing 1 to 19 of 19 parts
Related Assemblies
-
DIAG-J1-2-1-397915-12043145 J1-2-1 IDLER SPROCKET & TENSIONER UNIT
View Diagram -
DIAG-J1-5-1-397915 J1-5-1 TRACK ASSEMBLIES
View Diagram -
DIAG-F4-2-1-397915 F4-2-1 GEARBOX, TRACK
View Diagram
