Kubota L200/210 I02400 REAR FENDER Parts Diagram

Exploded-view parts diagram "I02400 REAR FENDER" for the Kubota L200/210. 24 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.

Scroll to zoom Click a part # to view details

Ref # Part Number Qty. Avl. Price (USD) Action
Rubber Cap 3G710-87770 32150-29180 1 2 IN STOCK $0.90
003 BOLT 01115-51238 1 AVAILABLE TO ORDER $6.27
004 Spring Washer 04512-60120 04512-70120 1 1 IN STOCK $0.36
005 SEAT ASSY*** 32140-18405 32140-18400 Discontinued 1 NO LONGER AVAILABLE $271.14
006 BRACKET SEAT*** 31210-18410 Discontinued 1 NO LONGER AVAILABLE $36.96
007 BOLT 01050-50822 01053-50822 1 6 IN STOCK $1.75
008 Spring Washer (Lock Washer) 04512-60080 04512-70080 1 15 IN STOCK $0.60
009 SHAFT, SEAT ADJ 32210-18423 32210-18420 Discontinued 1 NO LONGER AVAILABLE $11.01
010 PIN, SNAP ** 63803-34392 63803-34390 Discontinued 1 NO LONGER AVAILABLE $0.54
011 CUSHION 32160-18492 32160-18490 1 AVAILABLE TO ORDER $10.14
012 STAY SET 31210-18480 Discontinued 1 NO LONGER AVAILABLE $42.19
015 Nut 60009-61553 02054-50080 1 13 IN STOCK $2.01
016 FLASHER, LAMP AS 32240-34202 32240-34200 Discontinued 1 NO LONGER AVAILABLE $69.42
017 LENS 32240-34122 32240-34120 Discontinued 1 NO LONGER AVAILABLE $29.69
018 GASKET, LENS 32240-34222 Discontinued 1 NO LONGER AVAILABLE $16.27
019 LAMP 32150-34240 1 AVAILABLE TO ORDER $18.85
020 SOCKET, LAMP*** 32240-34272 Discontinued 1 NO LONGER AVAILABLE $29.04
021 CORD WITH SOCKET 32240-34170 Discontinued 1 NO LONGER AVAILABLE $11.78
023 Nut Fastener 02013-50060 02014-50060 1 18 IN STOCK $0.60
024 Plain Washer 04011-50060 04012-50060 1 16 IN STOCK $0.36
025 Spring Washer 04512-60060 04512-70060 1 33 IN STOCK $0.60
026 SCREW 03016-20625 03016-50625 1 6 IN STOCK $0.62
027 RING 32240-34290 Discontinued 1 NO LONGER AVAILABLE $9.29
028 BRACKET 31210-29152 31210-29150 Discontinued 1 NO LONGER AVAILABLE $28.00

Showing 1 to 24 of 24 parts
