Kubota L2501DT H44002 POSITION CONTROL LEVER [NEW] Parts Diagram
Exploded-view parts diagram "H44002 POSITION CONTROL LEVER [NEW]" for the Kubota L2501DT. 15 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | CYL.SIDE RH COVE 32430-41210 | 1 | $26.82 | |||
| 020 | O-Ring Seal 04810-00140 04817-00140 | 1 | $2.50 | |||
| 030 | Bolt Fastener for Equipment Assemblies 01120-50820 01123-50820 | 1 | $0.99 | |||
| 040 | LEVER, POSITION TC420-36850 | 1 | $81.55 | |||
| 050 | TUBE TD060-36130 | 1 | $32.82 | |||
| 060 | PIN, SPRING 05411-00525 | 1 | $1.31 | |||
| 070 | GRIP,LEVER 52300-32640 52300-32643 | 1 | $10.88 | |||
| 080 | GUIDE, HYD LEVER TC320-47600 | 1 | $40.01 | |||
| 090 | Flange Bolt - M8 x 1.25 x 16 mm 01754-50816 | 1 | $4.33 | |||
| 100 | STOPPER 34070-36130 | 1 | $8.64 | |||
| 110 | Bolt 01123-50816 | 1 | $0.80 | |||
| 120 | STOPPER TC402-36140 | 1 | $3.61 | |||
| 130 | Knob Screw M6 x 2 37410-52610 | 1 | $8.19 | |||
| 140 | Spring Washer (Spring Lock Washer) 04512-80060 04512-50060 | 1 | $0.36 | |||
| 150 | Washer 31351-18860 | 1 | $0.80 | |||
Showing 1 to 15 of 15 parts
