Kubota L5240HST-3 H21501 HYDRAULIC OIL LINE (STEERING) [OLD] Parts Diagram
Exploded-view parts diagram "H21501 HYDRAULIC OIL LINE (STEERING) [OLD]" for the Kubota L5240HST-3 and Kubota L5740HST-3. 14 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | COMP. PIPE, DELI TD270-56482 | 1 | $178.69 | |||
| 020 | BOLT,CONNECTING 66591-36250 TD350-56450 | 1 | $11.39 | |||
| 025 | SPRING 34076-66160 | 1 | $14.54 | |||
| 030 | Hydraulic Oil Line Gasket 67111-37180 | 1 | $2.50 | |||
| 040 | TUBE PS PIPE TD060-33590 TD060-33592 | 1 | $19.67 | |||
| 050 | CLAMP PIPE TD060-33570 | 1 | $9.88 | |||
| 060 | CLAMP (PS PIPE) TD060-33582 TD060-33583 | 1 | $23.87 | |||
| 070 | Flange Bolt - M8 x 1.25 x 16 mm 01754-50816 | 1 | $4.33 | |||
| 080 | HOSE, DELIVERY TD270-33523 | 1 | $129.59 | |||
| 090 | HOSE, DELIVERY TD270-33550 | 1 | $107.94 | |||
| 100 | ADAPTER 56811-27380 | 1 | $23.50 | |||
| 100 | JOINT TD270-33580 | 1 | $44.58 | |||
| 110 | HOLDER,HOSE TD060-33280 | 1 | $12.26 | |||
| 120 | Flange Bolt 01754-50830 | 1 | $5.85 | |||
Showing 1 to 14 of 14 parts
