Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | POST, STEERING 3C011-63342 3C011-63344 | 1 | $474.81 | |||
| 015 | BUSH 41071-31120 08511-01715 | 1 | $6.60 | |||
| 020 | STEERING SHAFT ( 3C001-62152 3C001-62153 | 1 | $179.25 | |||
| 030 | SHIM, CAMSHAFT 12681-16660 | 1 | $1.55 | |||
| 040 | CUSHION 3C001-62170 | 1 | $4.45 | |||
| 050 | O-RING 04811-15120 | 1 | $1.95 | |||
| 060 | Steering Post Bushing 3C081-63170 3C291-63170 | 1 | $24.45 | |||
| 070 | BOLT, FLANGE 3C211-63140 | 1 | $22.54 | |||
| 080 | COLLAR 3C211-63150 | 1 | $12.21 | |||
| 085 | O-Ring Seal 04811-00090 04816-00090 | 1 | $1.07 | |||
| 090 | M5 Series Plain Washer 04015-60080 04015-70080 | 1 | $0.60 | |||
| 095 | NUT 50591-62370 02556-50080 | 1 | $1.51 | |||
| 100 | BUSH, POST 37410-41340 | 1 | $8.57 | |||
| 105 | CUSHION 38240-18640 | 1 | $2.62 | |||
| 110 | WHEEL TD060-18110 | 1 | $239.24 | |||
| 120 | CAP/STEERING WHE 3C021-62580 TC230-18120 | 1 | $68.23 | |||
| 130 | Spring Washer 04512-60120 04512-70120 | 1 | $0.36 | |||
| 140 | Nut Fastener 70030-35018 02176-50120 | 1 | $1.07 | |||
| 150 | COVER, FRONT 3C081-63383 | 1 | $31.09 | |||
| 160 | COVER REAR (S/N> 3C081-63390 3C081-63393 | 1 | $27.62 | |||
| 170 | SCREW, SEMS (PAN T1880-43130 | 1 | $3.16 | |||
| 180 | Interlock Switch for Clutch/Brake and Differential Lock Controls 37150-15842 37150-15840 | 1 | $13.40 | |||
Showing 1 to 22 of 22 parts
