Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | CYL, TELESCOPIC 90565-11350 RC418-67300 | 1 | $4,664.75 | |||
| 020 | TUBE, CYL ASSY 90565-91410 | 1 | $4,397.13 | |||
| 030 | ROD, PISTON ASSY 90565-91510 | 1 | $1,829.20 | |||
| 040 | COVER, ROD 90435-11630 | 1 | $573.99 | |||
| 050 | GASKET, PISTON 90545-11810 Discontinued | 1 | $44.46 | |||
| 060 | PISTON 90435-11640 | 1 | $442.59 | |||
| 070 | BUSH PIN 90435-11650 | 1 | $206.55 | |||
| 080 | DU-BUSH 90435-11660 | 1 | $81.86 | |||
| 090 | U-NUT 68721-71392 | 1 | $58.33 | |||
| 100 | O-RING 90545-11820 | 1 | $5.70 | |||
| 100 | O-Ring Seal 04810-00180 04817-00180 | 1 | $2.26 | |||
| 110 | WIPER, ROD 68051-91190 | 1 | $19.33 | |||
| 120 | RING, BACK-UP 90545-11840 | 1 | $36.38 | |||
| 130 | GASKET 90545-11850 | 1 | $50.52 | |||
| 140 | O RING 04817-00440 | 1 | $4.85 | |||
| 140 | O-RING 90545-11860 | 1 | $10.46 | |||
| 150 | PIN, SPRING 90545-91620 Discontinued | 1 | $10.75 | |||
| 160 | KIT SEAL, TELESC 90545-91160 90545-91162 | 1 | $209.83 | |||
Showing 1 to 18 of 18 parts
Related Assemblies
-
DIAG-G20100-85182 G20100 ARM (TELESCOPIC)
View Diagram -
DIAG-G30000-85182 G30000 BUCKET LINK
View Diagram -
DIAG-G20000-85182 G20000 ARM
View Diagram
