Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | Valve trailer cont 15/920330 | 1 | $560.57 | |||
| 2 | MALE STUD 12MM - M16 816/65125 | 1 | $35.40 | |||
| 3 | .0MM TEE PIECE 816/90818 | 1 | $34.19 | |||
| 4 | BULKHEAD ADAPTOR M22 - 10 816/90832 | 1 | $32.88 | |||
| 5 | 12MM 'T' PIECE 816/90808 | 1 | $33.99 | |||
| 6 | PALM COUP SINGLE LINE 45/916500 45/920139 | 1 | $575.97 | |||
| 7 | AIR TUBE 10MM BLACK (300M Rolls) 647/14600 | 1 | $6.60 | |||
| 8 | BRACKET MOUNTING I 481/00482 | 1 | $58.97 | |||
| 9 | SET-SCREW M_8 L-_25mm 1315/0307D | 1 | $0.37 | |||
| 10 | NUT M_8 STD PLAIN 1370/0201Z 1370/0201D | 1 | $1.07 | |||
| 11 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 12 | PRESSURE REGULATOR (80PSI 331/51026 | 1 | $111.97 | |||
| 13 | 90 ELBOW 10MM - M22 816/90819 | 1 | $35.53 | |||
| 13A | O RING 2403/0013 | 1 | $1.79 | |||
| 14 | 90 ELBOW 10MM - M12 478/69800 816/90807 | 1 | $14.92 | |||
| 15 | BOLT M6x55 (R) 1315/3213D | 1 | $0.30 | |||
| 16 | NUT M_6 STD SELF LOCK 1370/0103 1370/0103D | 1 | $0.17 | |||
| 41 | M22 VENTED PLUG 816/90855 | 1 | $36.78 | |||
| 42 | Blanking Cap 816/90810 | 1 | $13.54 | |||
| 43 | M24 X 1.5 NUT 826/11389 | 1 | $5.10 | |||
| 44 | AIR TUBE 12 MM BLACK 300mtr roll 647/13600 | 1 | $8.12 | |||
Showing 1 to 21 of 21 parts
Related Assemblies
-
DIAG-G190-11-1-393600 G190-11-1 FOOT BRAKE CIRCUIT
View Diagram -
DIAG-L300-1-1-393600 L300-1-1 COMMON PARTS INDUCTION ASSEMBLY
View Diagram -
DIAG-G190-10-1-393600 G190-10-1 FOOT BRAKE ACTUATOR CIRCUIT NON ABS
View Diagram
