Kubota B2630HSD G13200 FRONT AXLE RH Parts Diagram
Exploded-view parts diagram "G13200 FRONT AXLE RH" for the Kubota B2630HSD and Kubota B3030HSD. 11 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | Differential Gear Shaft 67211-14990 | 1 | $9.48 | |||
| 010 | Differential Gear Shim 66621-15240 | 1 | $5.15 | |||
| 020 | GEAR, BEVEL 6C200-57370 | 1 | $537.61 | |||
| 020 | GEAR, BEVEL * 6C070-57310 | 1 | $508.21 | |||
| 030 | SHAFT, FRONT AXL 32721-57323 | 1 | $197.17 | |||
| 030 | SHAFT, FRONT AXL 6C360-57320 | 1 | $210.66 | |||
| 040 | Threaded Stud 66591-56565 66591-56564 | 1 | $8.66 | |||
| 050 | Ball Bearing PL501-12230 08101-06206 | 1 | $14.46 | |||
| 060 | 6305 Deep Groove Ball Bearing T2050-23480 08101-06305 | 1 | $15.41 | |||
| 070 | Front Axle / Wheel Hub Collar 67121-56820 67156-56820 | 1 | $23.66 | |||
| 080 | Oil Seal (Axle / Gear Shaft) 37410-57340 6E040-57340 | 1 | $19.66 | |||
Showing 1 to 11 of 11 parts
