Kubota B26 G12700 FRONT AXLE CASE RH Parts Diagram
Exploded-view parts diagram "G12700 FRONT AXLE CASE RH" for the Kubota B26. 7 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | CASE, GEAR RH 6C430-56320 6C200-56320 | 1 | $541.31 | |||
| 020 | BOLT, FLANGE 01774-51010 | 1 | $2.95 | |||
| 030 | Washer 04717-00100 04717-01000 | 1 | $2.26 | |||
| 040 | COVER, GEAR CASE 6C040-56345 6C040-56346 | 1 | $174.35 | |||
| 050 | PIN, STRAIGHT 05012-01020 | 1 | $1.51 | |||
| 060 | BOLT 01130-51028 01133-51028 | 1 | $2.47 | |||
| 060 | Bolt Fastener 01130-51030 01133-51030 | 1 | $2.54 | |||
Showing 1 to 7 of 7 parts
