Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| ROTOR KIT 15/915204 | 1 | $679.09 | ||||
| 1 | Disc parking brake 15/920176 | 1 | $580.72 | |||
| 2 | Bracket caliper 335/02381 | 1 | $835.93 | |||
| 3 | CALIPER - HAYES BRAKE M90 15/920272 15/M04039 | 1 | $1,568.53 | |||
| 10 | PIVOT BOLT M6x30 826/10837 | 1 | $17.09 | |||
| 11 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 12 | NUT M6 STD SELF LOCK(KANBAN) 1370/0103Z | 1 | $1.43 | |||
| 25 | SPACER 265/01744 | 1 | $22.20 | |||
| 35 | BOLT M20X75 1315/3817Z | 1 | $22.79 | |||
| 35A | SET SCREW M20x50 1315/0812Z | 1 | $2.75 | |||
| 36 | BOLT M16x70 1315/3716Z | 1 | $5.10 | |||
| 37 | WASHER M16 HARDENED 1422/0011D | 1 | $15.66 | |||
| 38 | (W) (P) WASHER M20 PLAIN 1420/0012Z | 1 | $2.82 | |||
| 39 | NUT M16 STD SELF LOCK 1370/0603Z | 1 | $2.66 | |||
Showing 1 to 14 of 14 parts
Related Assemblies
-
DIAG-G1-3-1-404582 G1-3-1 BRAKE, PARKING CONTROL
View Diagram -
DIAG-G1-2-2-404582 G1-2-2 BRAKE, CALIPER COMPONENTS
View Diagram -
DIAG-G1-2-1-404582 G1-2-1 BRAKE, CALIPER COMPONENTS THIS PAGE IS SUPERSEDED SEE G1-2-2
View Diagram
