Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| PARKBRAKE CALIPER 452/02000 15/920171 | 1 | $884.39 | ||||
| 2 | ARM - ADJUSTING 452/02300 | 1 | $449.12 | |||
| 3 | PIVOT SEAT 452/02400 | 1 | $449.33 | |||
| 4 | LEVER 452/02001 | 1 | $151.89 | |||
| 5C | NUT 1358/0204Z | 1 | $11.28 | |||
| 6 | PIN PIVOT 452/01002 811/30106 | 1 | $19.72 | |||
| 7 | ROD 452/03101 | 1 | $190.82 | |||
| 8 | WASHER -SPHERICAL 823/00487 | 1 | $67.44 | |||
| 9 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 10 | BOLT 826/00980 | 1 | $102.11 | |||
| 10A | NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $0.26 | |||
| 11 | SAFETY CLIP. 913/01102 | 1 | $3.18 | |||
| 12 | SPRING TORSION 814/00323 | 1 | $84.32 | |||
| 13 | HINGE PIN 452/02601 | 1 | $133.32 | |||
| 14 | BODY 452/02500 | 1 | $629.59 | |||
| 15 | CALIPER MTG. PLATE -UNIV 445/26107 | 1 | $331.94 | |||
| 17 | DOWEL BOLT 826/01265 | 1 | $42.96 | |||
| 19 | BOLT M10 x 25L 826/01084 | 1 | $5.25 | |||
| 20 | SHIM 819/00070 | 1 | $33.30 | |||
| 21 | SHIM 819/00071 | 1 | $31.27 | |||
Showing 1 to 20 of 20 parts
