Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | PEDAL 262/36100 | 1 | $253.37 | |||
| 1 | PEDAL-BRAKE 262/24900 | 1 | $573.28 | |||
| 2 | BRACKET 262/17400 | 1 | $238.41 | |||
| 2 | BRACKET 262/36200 | 1 | $349.00 | |||
| 3 | BOLT 3/8UNFx4" 1305/3230Z | 1 | $11.01 | |||
| 4 | WASHER 3/8in MEDIUM 1411/0003D | 1 | $0.48 | |||
| 5 | WASHER 1411/0006Z | 1 | $0.44 | |||
| 6 | (P) NUT 3/8UNF STD SELF LOCK 1340/0203Z | 1 | $1.75 | |||
| 7 | BEARING 16x20x25 831/00064 | 1 | $23.64 | |||
| 8 | PIVOT TUBE 830/00330 | 1 | $72.38 | |||
| 9 | (P) SET 3/8UNFx1 HT 1305/0206Z | 1 | $2.49 | |||
| 10 | SPACER BLOCK 262/17201 | 1 | $29.63 | |||
| 11 | CLEVIS 913/00020 | 1 | $80.68 | |||
| 12 | SPRING PIN 913/00021 | 1 | $42.28 | |||
| 13 | WASHER 823/00227 | 1 | $0.18 | |||
| 14 | SCREW NO8X1/2 1430/0202 | 1 | $0.41 | |||
| 15 | GAITER 262/17203 | 1 | $126.62 | |||
| 15 | GAITER 263/22404 | 1 | $451.49 | |||
| 16 | ADAPTOR 262/17204 | 1 | $94.65 | |||
| 18 | NUT M10 THIN PLAIN 1370/0302Z | 1 | $0.62 | |||
| 19 | NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $0.26 | |||
| 20 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 21 | VALVE 15/901500 | 1 | $725.80 | |||
| 21A | SERVO 15/901700 | 1 | $421.10 | |||
| 21B | VALVE 15/901501 | 1 | $18.57 | |||
| 21C | SEAL 15/901402 | 1 | $9.75 | |||
| 22 | MASTER CYLINDER 15/901800 | 1 | $296.66 | |||
| 24 | SPRING 814/00253 | 1 | $121.78 | |||
| 25 | SEAL FOAM 263/22405 | 1 | $66.00 | |||
Showing 1 to 29 of 29 parts
Related Assemblies
-
DIAG-G1-1-15-404653 G1-1-15 BRAKE, SYSTEM 4 WHEEL
View Diagram -
DIAG-G1-4-3-404653 G1-4-3 BRAKE, COMPONENTS FOOT
View Diagram -
DIAG-G1-1-6-404653 G1-1-6 BRAKE, PARKING COMPONENTS
View Diagram
