Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| SHIM 15/920134 | 1 | $20.85 | ||||
| 1 | BRAKE ASSEMBLY 15/920123 | 1 | $3,208.59 | |||
| 2 | Piston brake 15/920124 | 1 | $662.10 | |||
| 3 | Ring pressure 15/920125 | 1 | $988.36 | |||
| 4 | Pin pressure 15/920126 | 1 | $331.35 | |||
| 5 | BRAKE PAD KIT ) (Pair per KIT) 15/920127 | 1 | $987.80 | |||
| 6 | MAGNET 15/920128 | 1 | $110.18 | |||
| 7 | Ring clearance 15/920129 | 1 | $52.63 | |||
| 8 | DUST CAP 15/920130 | 1 | $128.16 | |||
| 9 | SEAL KIT 15/920286 | 1 | $623.05 | |||
| 11 | SPRING CUP 15/920133 | 1 | $143.64 | |||
| 13 | O RING 15/920135 | 1 | $27.63 | |||
| 14 | O RING 15/920136 | 1 | $16.83 | |||
| 15 | CIRCLIP 10/907129 | 1 | $15.33 | |||
| 16 | Cap screw 15/920137 | 1 | $209.92 | |||
| 17 | O RING 15/920138 | 1 | $14.58 | |||
| 18 | Breather 333/E5761 15/920139 | 1 | $45.74 | |||
| 19 | SCREW ADJ 15/920140 | 1 | $44.69 | |||
| 20 | NUT HEX 15/920141 | 1 | $16.87 | |||
| 21 | PIN 15/920282 | 1 | $229.51 | |||
| 22 | Plate anchor 15/920122 | 1 | $1,268.72 | |||
| 23 | DISC, BRAKE (8-MOUNTING HOLE) 15/920121 | 1 | $2,241.36 | |||
| 24 | BOLT M12x40 1316/3510Z | 1 | $3.30 | |||
| 25 | SET SCREW M10x25(KANBAN) 1316/0407Z | 1 | $1.64 | |||
| 26 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 81 | ADAPTOR G1/4A-G1/8A 1606/0001 1606/2050 | 1 | $8.46 | |||
Showing 1 to 26 of 26 parts
Related Assemblies
-
DIAG-G1-3-1-404930 G1-3-1 HOSE AND PIPEWORK PARK BRAKE VALVE ACCUMULATORS
View Diagram -
DIAG-G1-1-1-404930 G1-1-1 VALVE, BRAKE
View Diagram -
DIAG-F6-1-1-404930-15830314 F6-1-1 COOLER, OIL TRANSMISSION AIR BLAST
View Diagram
