Kubota T1670 G04002 SEAT Parts Diagram
Exploded-view parts diagram "G04002 SEAT" for the Kubota T1670, Kubota T1670A, Kubota T1770, Kubota T1870 and Kubota T1870A. 16 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | SEAT,KIT(V-3500) K1122-56110 K1241-93010 | 1 | $548.40 | |||
| 020 | BOLT, FLANGE (5/ 0Y171-50508 | 1 | $1.99 | |||
| 030 | SPRING, SEAT SW K1122-56142 K1122-56140 | 1 | $1.85 | |||
| 040 | Metric Hex Lock Nut K5112-72840 K5112-72842 | 1 | $0.36 | |||
| 050 | WASHER, FLAT 5/1 75599-32112 Discontinued | 1 | $0.37 | |||
| 060 | SUPPORT, SEAT K1211-56120 | 1 | $220.50 | |||
| 070 | SPRING,LOCK K1211-56150 K1211-56152 | 1 | $2.42 | |||
| 080 | COVER, LEVER K1211-56140 | 1 | $1.23 | |||
| 090 | NUT NYLON LOCK P 77700-04169 75599-31923 | 1 | $0.59 | |||
| 100 | WASHER, FLAT 3/8 75599-32113 | 1 | $0.39 | |||
| 110 | Seat K2561-98810 Discontinued | 1 | $778.87 | |||
| 130 | PLATE, SEAT KIT K2561-98820 | 1 | $36.86 | |||
| 140 | Hex Bolt 5/16" x 1" 70002-00418 75599-01220 | 1 | $0.80 | |||
| 150 | Plain (Flat) Washer 60009-60701 75599-32012 | 1 | $0.14 | |||
| 160 | EX INSTRUCTION, K2561-98830 Discontinued | 1 | $10.47 | |||
| 170 | EX KIT SEAT ADAP K2561-98910 | 1 | $66.80 | |||
Showing 1 to 16 of 16 parts
